The use characteristics and daily maintenance methods of intelligent palletizing robot

The use characteristics of intelligent palletizing robot

1. Accurate induction: The robot can flexibly and freely determine the working position in all directions within the working radius. Accuracy up to ± 0.1mm, can accurately sense the position of the material, grab and put into the specified position.

2. Simple operation: Chinese man-machine interface, the operator can easily modify parameters and select programs on the interface, so as to control the robot.

3. Flexible production: According to the needs of the actual production process, the robot can replace and install different claws to meet the needs of flexible production. The robot can also work with a laser vision inspection system to identify the type of workpiece and help the robot locate the workpiece. It can also be integrated into multiple production lines for different material stacking operations.

4. High degree of automation: The operation of intelligent palletizing robot relies on program control, without manual participation, high degree of automation, saving a lot of manpower.

5. High efficiency: The packaging robot works fast and has no time break, so the work efficiency is relatively high.

Routine maintenance method of intelligent palletizing robot

1. Before each operation of the palletizing system, the operator should check whether there are screws loosening, circuit aging, connection file slipping, belt cracking and other problems. If there is any problem, it should be solved immediately to prevent any failure during operation.

2. Clean up smart palletizing robots in time. The smart palletizing robot should be carefully cleaned before leaving work every day and wiped clean with a dry rag. If it is difficult to clean with a rag, you may as well use a brush.

3. The tooth belt and reverse connection equipment of the automatic palletizing system have a service life, and should be replaced immediately after the expiration to prevent hidden dangers.

4. See if the lubricating oil still works. After the robot stacker works for 3 months, it is necessary to check whether the lubricating oil of the vacuum pump is dirty or less. If it is dirty, replace it in time; If there is less, make it up as soon as possible.

5. In the workplace, corrosive liquids should be prohibited to prevent the metal manipulator from being corroded. When the circuit control board fails, it should be stopped immediately for inspection.

6. The bottom surface of the intelligent palletizing robot should be used reasonably. All four sides of the robot stacker can be used. For example, if your floor is uneven, four silicone MATS can be adjusted to level the robot stacker.

7. Some robot stackers will have high temperature cloth scrolls on them, which will absorb heat. If the reel is burned, it should be replaced immediately.
